- Fully compliant with medical safety directives
- New Full Flat design for Front panel
- New IPS panel with LED backlight (450 cd/㎡)
- High Resolution, True color display (1.07 Billion Color gradient）
- Jaggy-less I / P Conversion Process
- Multiple Input and Format Capabilities
Ikegami MLW2624C (MLW-2624C) 26" Surgical Display
Ikegami MLW2624C (MLW-2624C) 26″ Surgical Display
Ikegami MLW2624C (MLW-2624C) is a wide screen 26-inch LCD monitor with the high resolution 1920 (H) x 1080 (V) Full HD LCD panel, maximum intensity of 450 cd / m2 and wide angle of 178 degrees. Also, Ikegami MLW2624C (MLW-2624C) employs the touch switch control panel to improve the operability during operation.
12 bit signal process engine
12-bit signal processing based on Ikegami image processing technology allows the smooth
gradation of color.
10-bit LCD panel
Further smooth color gradation can be achieved by processing 10 bit signal from signal
input to display.
178 degrees high contrast viewing angle
LCD panel based on IPS technology is employed for 178 degrees high contrast viewing on
UP/DOWN/LEFT/RIGHT. This characteristic prevents from intensity and color shift by the
Images can be flipped horizontally and vertically, allowing the correction of image inversion
caused by the optics.
Automatic contrast adjust functions
Based on brightness on the image, monitor will be able to expand each dynamic range of
black and white automatically.
Picture and Picture, Side by Side
SDI signal input can be combine to show as P in P or Side by Side with other signal input
(DVI-D, S-Video, Component, RGB or Video).
Color temperature switching function
The color temperatures can be chosen from 6500K, 9300K and user settings to select
a color rendering to your taste.
User setting memory switching function
Colors, brightness and other image quality-related settings are user-adjustable for
eight different groups. They are readily switchable.
